Omron SYSMAC CJ1W-SCU41-V1 User Manual

400
C-mode (Host Link) Command Master Appendix C
LR AREA READ (RL Command)
(Sequence No. 703 (Hex 02BF))
Reads the contents of the specified number of LR Area (CS/CJ Series: CIO 1000 to CIO 1199) words begin-
ning with the designated word from the specified Host Link Unit and stores starting from the specified storage
word.
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
Offset Contents (data format) Data
+0
Number of send data words Always 0004 hex (4 decimal)
+1
(Undefined) Host Link unit
No.
(2 digits BCD)
00 to 31
+2
First read word (4 digits BCD) 0000 to 0199
+3
Number of read words
(4 digits BCD)
Depends on the remote CPU Unit.
+0
+1
+2
+3
(Undefined)
Number of read words
First read word
First word of
send data
Number of send data words
Host Link unit No.
Offset Contents (data format) Data
+0
Number of receive data words 0003 to 00FA hex (3 to 250 decimal)
+1
(Undefined) End code
(2 digits hex)
The end code is stored in hexadecimal.
+2
Read data (4 digits hex) The contents of the first read word is
stored
+3
The contents of the first read word +1
is stored
+0
+1
+2
Read data
Receive data
storage words
Number of receive data words
(Undefined) End code
