Omron SYSMAC CJ1W-SCU41-V1 User Manual

402
C-mode (Host Link) Command Master Appendix C
TIMER/COUNTER PV READ (RC Command)
(Sequence No. 705 (Hex 02C1))
Reads the contents of the specified number of timer/counter PV words (T0000 to T2047, C0000 to C2047)
beginning with the designated word from the specified Host Link Unit and stores starting from the specified
storage word.
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
Offset Contents (data format) Data
+0
Number of send data words Always 0004 hex (4 decimal)
+1
(Undefined) Host Link unit
No.
(2 digits BCD)
00 to 31
+2
First read word (4 digits BCD) Timers: T0000 to T2047
Counters: C2048 to C4095
Note: Specify T0000 to T2047 for tim-
ers and in C2048 to C4095 for
counters.
+3
Number of read words
(4 digits BCD)
Depends on the remote CPU Unit.
+0
+1
+2
+3
(Undefined)
Number of read words
First read word
First word of
send data
Number of send data words
Host Link unit No.
Offset Contents (data format) Data
+0
Number of receive data words 0003 to 00FA hex (3 to 250 decimal)
+1
(Undefined) End code
(2 digits hex)
The end code is stored in hexadecimal.
+2
Read data (4 digits hex or BCD)
(Depends on the method used to
refresh the timer/counter PVs.)
The contents of the first read word is
stored
+3
The contents of the first read word +1
is stored
+0
+1
+2
Read data
Receive data
storage words
Number of receive data words
(Undefined) End code
