E5 @ K Digital Controller Write Protocol Appendix G
Receive Data Word Allocation (4th Operand of PMCR(260))
None.
Write Manual Reset Value (Sequence No. 055 (Hex 0037))
Writes the manual reset value.
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
None.
Write Hysteresis (Sequence No. 056 (Hex 0038))
Writes the hysteresis for heating and for cooling.
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
None.
Write Control Period (Sequence No. 057 (Hex 0039))
Writes the control period for heating and for cooling.
Send Data Word Allocation (3rd Operand of PMCR(260))
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0003 (fixed)
+1 Unit No. (2 digits BCD) 00 to 31
+2 Manual reset value (4 digits BCD) 0000 to 1000
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0004 (fixed)
+1 Unit No. (2 digits BCD) 00 to 31
+2 Hysteresis (heating)
(4 digits BCD)
0001 to 9999
+3 Hysteresis (cooling)
(4 digits BCD)
0001 to 9999
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0004 (fixed)
+1 Unit No. (2 digits BCD) 00 to 31
First word of
send data
Number of send data words+0
+1
+2
(Undefined) Unit No.
Manual reset value
First word of
send data
Number of send data words
+0
+1
+2
+3
(Undefined) Unit No.
Hysteresis (heating)
Hysteresis (cooling)
First word of
send data
Number of send data words
+0
+1
+2
+3
(Undefined) Unit No.
Control period (heating)
Control period (cooling)
