Specifications Section 1-6
Note The current consumption is for one Serial Communications Board or Unit.
When an NT-AL001-E Link Adapter is connected to the Serial Communica-
tions Board or Unit, power is supplied to the Link Adapter from the Board or
Unit. A current consumption of 150 mA must be added for each Link Adapter
that is connected. In the above specifications, “x” indicates that 150 mA must
be added for each port to which an NT-AL001-E Link Adapter is connected to
provide the required 5-V power supply.
Applicable Backplanes None CPU Backplanes:
CS1W-
BC103/BC083/BC053/BC033/BC023
CS Expansion Backplanes:
CS1W-BI103/BI083/BI053/BI033
Current consumption (See note.) 280 mA + x 360 mA + x 290 mA + x 400 mA
Weight 100 g max. 110 g max. 200 g max. 250 g max.
Device name Serial Communications Boards Serial Communications Unit
