Omron SYSMAC CJ1W-SCU41-V1 User Manual

508
E5ZE Temperature Controller Read Protocol Appendix H
Read Set Point, Process Value, and Output Value
(Sequence No. 103 (Hex 0067))
Reads the set points, process values, and output values and stores the results in the specified words.
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
Offset Contents (data format) Data
+0 Number of receive data words
(4 digits Hex)
0011 (0017 decimal)
+1 Channel 0
Output value (4 digits BCD)
0000 to 1000
+2 Channel 0
Cooling output value (4 digits BCD)
0000 to 1000
+3 Channel 1
Output value (4 digits BCD)
0000 to 1000
+4 Channel 1
Cooling output value (4 digits BCD)
0000 to 1000
•
•
•
+15 Channel 7
Output value (4 digits BCD)
0000 to 1000
+16 Channel 7
Cooling output value (4 digits BCD)
0000 to 1000
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0002 (fixed)
+1 Unit No. (2 digits Hex) 00 to 0F
First word of
send data
Number of send data words+0
+1
(Undefined) Unit No.
Receive data
storage words
Number of receive data words
+0
+1
+2
+3
+4
+5
+36
+37
+38
+39
+40
Set point (rightmost 4 digits)
~ ~
Set point (leftmost 1 digit)
Channel 0
Channel 7
Process value (rightmost 4 digits)
Output value
Process value (leftmost 1 digit)
Set point (rightmost 4 digits)
Set point (leftmost 1 digit)
Process value (rightmost 4 digits)
Output value
Process value (leftmost 1 digit)
