E5ZE Temperature Controller Read Protocol Appendix H
Read Output Mode (Sequence No. 106 (Hex 006A))
Reads the output modes (normal/reverse) and stores the results in the specified words.
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
Read Alarm Mode (Sequence No. 107 (Hex 006B))
Reads the alarm modes and stores the results in the specified words.
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0002 (fixed)
+1 Unit No. (2 digits Hex) 00 to 0F
Offset Contents (data format) Data
+0 Number of receive data words
(4 digits Hex)
0002
+1 Set code (2 digits Hex) 00 to FF
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0002 (fixed)
+1 Unit No. (2 digits Hex) 00 to 0F
Offset Contents (data format) Data
+0 Number of receive data words
(4 digits Hex)
0011 (0017 decimal)
+1 Channel 0
Alarm 1 set code (2 digits Hex)
00 to 0C
+2 Channel 0
Alarm 2 set code (2 digits Hex)
00 to 0C
•
•
•
+15 Channel 7
Alarm 1 set code (2 digits Hex)
00 to 0C
+16 Channel 7
Alarm 2 set code (2 digits Hex)
00 to 0C
First word of
send data
Number of send data words
+0
+1
(Undefined) Unit No.
Receive data
storage words
Number of receive data words
(Undefined) Set code
+0
+1
First word of
send data
Number of send data words
+0
+1
(Undefined) Unit No.
Alarm 1 set code
Receive data
storage words
Number of receive data words
+0
+1
+2
+3
+4
+15
+16
(Undefined)
~ ~
Channel 0
Channel 7
Channel 1
Alarm 1 set code
(Undefined) Alarm 2 set code
(Undefined) Alarm 1 set code
(Undefined) Alarm 2 set code
(Undefined)
(Undefined) Alarm 2 set code
