E5ZE Temperature Controller Read Protocol Appendix H
Receive Data Word Allocation (4th Operand of PMCR(260))
Read Ramp Value (Sequence No. 115 (Hex 0073))
Reads the ramp values and stores the results in the specified words.
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
Offset Contents (data format) Data
+0 Number of receive data words
(4 digits Hex)
0009
+1 Channel 0
Manual reset value
(4 digits BCD)
0000 to 1000
+2 Channel 1
Manual reset value
(4 digits BCD)
0000 to 1000
•
•
•
+8 Channel 7
Manual reset value
(4 digits BCD)
0000 to 1000
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0002 (fixed)
+1 Unit No. (2 digits Hex) 00 to 0F
Offset Contents (data format) Data
+0 Number of receive data words
(4 digits Hex)
0011 (0017 decimal)
+1 Channel 0
Ramp value (3 digits BCD)
000 to 999
+2 Channel 0
Time unit (one ASCII character)
S: Seconds; M: Minutes; H: Hours
•
•
•
Receive data
storage words
Number of receive data words
+0
+1
+2
+8
Manual reset value
~ ~
Manual reset value
Manual reset value
Channel 0
Channel 7
Channel 1
First word of
send data
Number of send data words+0
+1
(Undefined) Unit No.
Ramp value
Receive data
storage words
Number of receive data words
+0
+1
+2
+3
+4
+15
+16
(Undefined)
~ ~
Channel 0
Channel 7
Channel 1
Ramp value
Time unit (Undefined)
(Undefined)
Ramp value
Time unit (Undefined)
(Undefined)
Time unit (Undefined)
