E5ZE Temperature Controller Read Protocol Appendix H
Read HB Alarm and HS Alarm Valid Channels
(Sequence No. 119 (Hex 0077))
Reads the valid or invalid channels for HB alarms and HS alarms and stores the results in the specified words.
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
Read Heater Burnout and SSR Failure Detection Currents
(Sequence No. 120 (Hex 0078))
Reads the heater burnout and SSR failure detection currents and stores the results in the specified words.
Send Data Word Allocation (3rd Operand of PMCR(260))
Offset Contents (data format) Data
+0 Number of receive data words
(4 digits Hex)
0009
+1 Channel 0
Output value change rate limit
(4 digits BCD)
0000 to 1000
+2 Channel 1
Output value change rate limit
(4 digits BCD)
0000 to 1000
•
•
•
+8 Channel 7
Output value change rate limit
(4 digits BCD)
0000 to 1000
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0002 (fixed)
+1 Unit No. (2 digits Hex) 00 to 0F
Offset Contents (data format) Data
+0 Number of receive data words
(4 digits Hex)
0009
+1 Set code (2 digits Hex) 00 to FF
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0002 (fixed)
+1 Unit No. (2 digits Hex) 00 to 0F
First word of
send data
Number of send data words
+0
+1
(Undefined) Unit No.
Receive data
storage words
Number of receive data words+0
+1
(Undefined) Set code
First word of
send data
Number of send data words
+0
+1
(Undefined) Unit No.
