E5ZE Temperature Controller Read Protocol Appendix H
Read Cooling Coefficient (Sequence No. 123 (Hex 007B))
Reads the cooling coefficients and stores the results in the specified words.
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0002 (fixed)
+1 Unit No. (2 digits Hex) 00 to 0F
Offset Contents (data format) Data
+0 Number of receive data words
(4 digits Hex)
0009
+1 Channel 0
Cooling coefficient (4 digits BCD)
0000 to 0100
+2 Channel 1
Cooling coefficient (4 digits BCD)
0000 to 0100
•
•
•
+8 Channel 7
Cooling coefficient (4 digits BCD)
0000 to 0100
First word of
send data
Number of send data words
+0
+1
(Undefined) Unit No.
Receive data
storage words
Number of receive data words+0
+1
+2
+8
Cooling coefficient
~ ~
Cooling coefficient
Cooling coefficient
Channel 0
Channel 7
Channel 1
