E5ZE Temperature Controller Write Protocol Appendix I
Receive Data Word Allocation (4th Operand of PMCR(260))
None.
Note When the setting unit for the set point is 0.1 (5 digits), use Write Set Point (Setting Unit 0.1), Sequence
No.151.
Write Set Point (Setting Unit 0.1) (Sequence No. 151 (Hex 0097))
Writes the set points using a setting unit of 0.1 (5 digits).
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
None.
Note When the setting unit for the set point is 1 (4 digits), use Write Set Point (Setting Unit 1), Sequence
No.150.
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0012 (0018 decimal) (fixed)
+1 Unit No. (2 digits Hex) 00 to 0F
+2 Channel 0
Set point
(4 digits BCD)
Varies according to the temperature sensor
type. Refer to the manual for the E5ZE.
•
•
•
+16 Channel 7
Set point
(4 digits BCD)
Varies according to the temperature sensor
type. Refer to the manual for the E5ZE.
+17 Not used ---
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0012 (0018 decimal) (fixed)
+1 Unit No. (2 digits Hex) 00 to 0F
+2 Channel 0
Set point (rightmost 4 digits)
(4 digits BCD)
Varies according to the temperature sensor
type. Refer to the manual for the E5ZE.
+3 Channel 0
Set point (leftmost 1 digit) (1 digit BCD)
•
•
•
+16 Channel 7
Set point (rightmost 4 digits)
(4 digits BCD)
Varies according to the temperature sensor
type. Refer to the manual for the E5ZE.
+17 Channel 7
Set point (rightmost 1 digit)
(1 digit BCD)
First word of
send data
Number of send data words
+0
+1
+2
+3
+4
+5
+16
+17
(Undefined) Unit No.
Set point (rightmost 4 digits)
~ ~
Set point (leftmost 1 digit)
Set point (rightmost 4 digits)
Set point (leftmost 1 digit)
Channel 0
Channel 7
Set point (rightmost 4 digits)
Set point (leftmost 1 digit)
Channel 1
