E5ZE Temperature Controller Write Protocol Appendix I
Receive Data Word Allocation (4th Operand of PMCR(260))
None.
Write Dead Band/Overlap Band (Sequence No. 172 (Hex 00AC))
Writes the dead bands or overlap bands for control outputs during heating/cooling control.
Send Data Word Allocation (3rd Operand of PMCR(260))
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0012 (0018 decimal) (fixed)
+1 Unit No. (2 digits Hex) 00 to 0F
+2 Channel 0
Heater burnout detection current
(4 digits BCD)
0000 to 0500
+3 Channel 0
SSR failure detection current
(4 digits BCD)
0000 to 0500
+4 Channel 1
Heater burnout detection current
(4 digits BCD)
0000 to 0500
+5 Channel 1
SSR failure detection current
(4 digits BCD)
0000 to 0500
•
•
•
+16 Channel 7
Heater burnout detection current
(4 digits BCD)
0000 to 0500
+17 Channel 7
SSR failure detection current
(4 digits BCD)
0000 to 0500
First word of
send data
Number of send data words
+0
+1
+2
+3
+4
+5
+6
+7
+8
+9
(Undefined) Unit No.
Dead band/overlap band
Dead band/overlap band
Channel 0
Channel 1
Dead band/overlap band
Channel 2
Dead band/overlap band
Channel 3
Dead band/overlap band
Channel 4
Dead band/overlap band
Channel 5
Dead band/overlap band
Channel 6
Dead band/overlap band
Channel 7
