Omron SYSMAC CJ1W-SCU41-V1 User Manual

612
K3T @ Intelligent Signal Processor Protocol Appendix L
Receive Data Word Allocation (4th Operand of PMCR(260))
Read Set Value HH with Bank (Continuous Units)
(Sequence No. 323 (Hex 0143))
This sequence reads set value HH of a bank not in use for continuous units.
Send Data Word Allocation (3rd Operand of PMCR(260))
`
Receive Data Word Allocation (4th Operand of PMCR(260))
The word allocation is similar to sequence No. 322 (Read Set Value with Bank (by Unit Number)).
Read Set Value H with Bank (Continuous Units)
(Sequence No. 324 (Hex 0144))
This sequence reads set value H of a bank not in use for continuous units. The word allocation is identical to
that of sequence No. 323 (Read Set Value HH with Bank (Continuous Units)).
Offset Contents (data format) Data
+0 Number of receive data
words (4 digits Hex)
0003 to 0041 (3 to 65 decimal)
+1 to +2 Set value
(5 digits BCD)
•
•
•
+63 to
+64
Set value
(5 digits BCD)
Same as above
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0003 to 0022 (3 to 34 decimal)
+1 Number of units (4 digits Hex) 0001 to 0020 (1 to 32 decimal)
+2 Bank No. (2 digits BCD) 01 to 04
•
•
•
+ 33 Bank No. (2 digits BCD) Same as above
+0
+1
+2
+63
+64
~
~
Number of receive data wordsReceive data
storage words
Set value
(Undefined) Set value
Set value
(Undefined) Set value
00000 to 99999
Negative sign: F (5th digit in BCD)
Example 12345
+1
+2
2345
0001
Example –1234
+1
+2
1234
000F
Bank No.
Number of units
+0
+1
+2
+33
Number of send data wordsFirst word of
send data
~ ~
Bank No.
(Undefined)
(Undefined)
