Omron SYSMAC CJ1W-SCU41-V1

634
3Z4L Laser Micrometer Protocol Appendix N
416 (01A0) Statistic processing execution
(3000-series)
Lights the statistic processing LED
and processes the statistics.
No No
417 (01A1) Statistic processing non-exe-
cution (3000-series)
Turns OFF the statistic processing
LED. Statistics are not processed.
No No
418 (01A2) All statistic memory clear
(3000-series)
Clears statistic processing memories
of all programs.
No No
419 (01A3) Statistic memory clear
(3000-series)
Clears statistic processing memories
of program under display.
No No
420 (01A4) Statistic result request
(3000-series)
Requests statistic processing result. No Yes
421 (01A5) Memory switch set 1
(3000-series)
Sets memory switches. Yes No
422 (01A6) Memory switch set 2
(3000-series)
Sets memory switches. Yes No
423 (01A7) Simple AVG times set
(3000-series)
Taking the simple average as the
averaging method, sets the averaging
times per measurement interval 4.
Ye s N o
424 (01A8) AVG move interval set
(3000-series)
Taking the average move as the aver-
aging method, sets the measure-
ment interval number.
Ye s N o
425 (01A9) AVG move (H) times set
(3000-series)
Taking the average move and high-
speed data output as the averaging
method, sets the averaging times per
measurement interval 4.
Ye s N o
426 (01AA) AVG move (L) times set
(3000-series)
Taking the average move and low-
speed data output as the averaging
method, sets the averaging times per
measurement interval 4.
Ye s N o
427 (01AB) Automatic detection set
(3000-series)
Sets work automatic detection func-
tion.
Ye s N o
428 (01AC) Automatic detection release
(3000-series)
Releases the settings of work auto-
matic detection function.
No No
429 (01AD) Automatic detection list
request (3000-series)
Requests the settings of work auto-
matic detection function.
No Yes
430 (01AE) 3Z4L initialize (3000-series) Clears the 3Z4L, sets the mm unit,
sets the memory unit, does not pro-
cesses statistics, and clears all statis-
tic memory.
Ye s N o
431 (01AF) Measurement condition set
(4000-series)
Sets measurement conditions. Yes No
432 (01B0) Measurement condition
release (4000-series)
Releases measurement conditions
that have been set.
Ye s N o
433 (01B1) Measurement condition list
request (4000-series)
Requests the measurement condi-
tions that have been set and other
settings.
No Yes
434 (01B2) Single run measurement start
(4000-series)
When the sample measurement con-
dition is from 1 to 999, performs a sin-
gle run measurement and requests
the measurement results.
No Yes
435 (01B3) Deflection measurement start
(4000-series)
Starts a deflection measurement. No No
436 (01B4) Continuous measurement start
(scan) (4000-series)
Starts a continuous measurement.
The scan notification method is used
for receive data.
No Yes
Sequence
No.
Communications sequence
name
Function Ladder interface Notes
Send word
allocation
Receive
word allo-
cation
