3Z4L Laser Micrometer Protocol Appendix N
AVG Move Interval Set (3000-series, High-speed Type)
(Sequence No. 424 (Hex 01A8))
This sequence uses the average move as the averaging method and sets the measurement interval number.
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
None.
Note This sequence cannot be used when DIP switch SW3, pin 5 of the Laser Micrometer is not turned ON.
AVG Move (H) Times Set (3000-series, High-speed Type)
(Sequence No. 425 (Hex 01A9))
This sequence uses the average move and high-speed data output as the averaging method and sets the aver-
aging times per measurement interval 4.
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
None.
Note This sequence cannot be used when DIP switch SW3, pin 5 of the Laser Micrometer is not turned ON.
AVG Move (L) Times Set (3000-series, High-speed Type)
(Sequence No. 426 (Hex 01AA))
This sequence uses the average move and low-speed data output as the averaging method and sets the aver-
aging times per measurement interval 4.
Send Data Word Allocation (3rd Operand of PMCR(260))
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0002 (fixed)
+1 Measurement interval number
(1 digit BCD)
1 to 4
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0002 (fixed)
+1 Number of averaging times
(4 digits BCD)
16 to 2048
(32 to 2048 for 5000/6000 Series)
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0002 (fixed)
+1 Number of averaging times
(4 digits BCD)
32 to 2048
First word of send
data
Number of send data words
+0
+1 (Undefined) Measurement interval number
First word of send
data
Number of send data words+0
+1 Number of averaging times
First word of send
data
Number of send data words+0
+1
Number of averaging times
