Visual Inspection System Protocol Appendix O
Receive Data Word Allocation (4th Operand of PMCR(260))
None.
Scene Switching (Arbitrary) (Sequence No. 492 (Hex 01EC))
This sequence switches to a designated scene No.
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
None.
Measurement, Inspection Termination (Sequence No. 493 (Hex
01ED))
This sequence terminates the measurement and returns to the home menu.
Send Data Word Allocation (3rd Operand of PMCR(260))
None.
Receive Data Word Allocation (4th Operand of PMCR(260))
None.
General-purpose Command (Send) (Sequence No. 494 (Hex
01EE))
This sequence can set and execute commands that are not otherwise supported. The delimiter (CR+LF) is
automatically attached to the send data.
Send Data Word Allocation (3rd Operand of PMCR(260))
Receive Data Word Allocation (4th Operand of PMCR(260))
None.
Note 1. The processing depends on the command.
2. For a command with a response, use sequence #495.
Offset Contents (data format) Data
+0 Number of send data words
(4 digits BCD)
0002
+1 Scene No. (2 digits BCD) 00 to 15
Offset Contents (data format) Data
+0 Number of send data words
(4 digits Hex)
0003 to 00FA (3 to 250 decimal)
+1 Command length (4 digits Hex) 0001 to 01F0 (1 to 496 decimal)
+2 to Command (ASCII) Specify ASCII data.
First word of
send data
Number of send data words
+0
+1 (Undefined) Scene No.
Command length
(Undefined)
First word of
send data
Number of send data words
+0
+1
+2 Command
~ ~
