49
Basic Operating Procedure Section 1-9
NT Link Mode
The following table shows the default (standard) settings for NT link when the
maximum PT unit number is 5.
m = D30000 + 100
× unit number
Serial Gateway
Using Serial Gateway Alone
1. Make the settings in the Setup Area.
m = D30000 + 100
× unit number
2. Set the local network table in the routing tables as required (using CX-Net).
Using Serial Gateway During Protocol Macro Execution
1. Make the settings in the Setup Area.
m = D30000 + 100
× unit number
D32008 D32018 m + 8 m + 18 15 0 Half-duplex
D32009 D32019 m + 9 m + 19 15 to 00 00C8 hex Maximum number of bytes in protocol
macro send/receive data: 200 bytes
Board
(CS Series only)
Unit
(CS/CJ Series)
Bit Setting Meaning
Port 1 Port 2 Port 1 Port 2
Board
(CS Series only)
Unit
(CS/CJ Series)
Bit Setting Meaning
Port 1 Port 2 Port 1 Port 2
D32000 D32010 m m + 10 11 to 08 2 1:N NT Link
D32001 D32011 m + 1 m + 11 03 to 00 0 The baud rate is set to the standard NT link
setting when the default settings are used.
D32006 D32016 m + 6 m + 16 02 to 00 5 1:N NT Link maximum unit number
(example)
Board
(CS Series only)
Unit
(CS/CJ Series)
Bit Setting Meaning
Port 1 Port 2 Port 1 Port 2
D32000 D32010 m m+10 15 0 Start bits: 1 bit
Data length: 7 bits
Parity: Even
Stop bits: 2
Baud rate: 9,600 bps
11 to 08 9 hex Serial communications mode: Serial Gate-
way
D32002 D32012 m+2 m+12 15 0 Send delay: 0 ms
D32003 D32013 m+3 m+13 15 0 CTS control: No
D32007 D32017 m+7 m+17 15 to 08 00 hex Response timeout monitoring time: 5 s
Board
(CS Series only)
Unit
(CS/CJ Series)
Bit Setting Meaning
Port 1 Port 2 Port 1 Port 2
D32000 D32010 m m+10 11 to 08 6 hex Serial communications mode: Protocol
macro
D32002 D32012 m+2 m+12 15 0 Send delay: 0 ms
D32003 D32013 m+3 m+13 15 0 CTS control: No
D32007 D32017 m+7 m+17 15 to 08 00 hex Response timeout monitoring time: 5 s
07 to 00 00 hex Serial Gateway send start timeout monitor-
ing time: 5 s
