1 Introduction to the Soft-NA
1 - 4
NA-series Programmable Terminal Soft-NA User’s Manual (V126)
1-3 Differences from NA-series Program-
mable Terminals
The Soft-NA and NA-series Programmable Terminals have the following differences:
*1. Equivalent functionalities can be implemented by using the Windows functions.
1-3-1 Differences Concerning System Specifications
Item NA5-series PT Soft-NA
Hardware Dedicated hardware Commercially-available PC
Resolution Fixed as either of the following depend-
ing on the model
• 1280 x 800
• 800 x 480
The following settings can be made on
Sysmac Studio
• 1920 x 1080
• 1280 x 800
• 800 x 480
Connectible controllers • NX/NJ/NY-series Controllers
•NX-CSG320
• CJ-series PLC
• CK3-series Programmable Multi-Axis
Motion Controllers
• NX/NJ/NY-series Controllers
•NX-CSG320
Project data transfer
method
• Media (USB memory, SD memory
card)
• Ethernet
•USB
• Media (USB memory, SD memory
card)
• Ethernet
Supported Runtime 1.03 to 1.13 1.11
NTP client Available
None
*1
FINS communications Supported Not supported
VNC functionality Available
None
*1
Document viewing Supported by an internal application A separate corresponding application is
required
Video playback Supported by an internal application A separate corresponding application is
required
Japanese/Asian language
input
Japanese/Chinese (simplified, tradi-
tional)/Korean are available for data
input objects
To enter Japanese/Chinese (simplified,
traditional)/Korean in data input objects,
use an on-screen keyboard of Windows
1-3-2 Differences Concerning the Overall Runtime Operation
Item NA5-series PT Soft-NA
Startup Power ON Run Soft-NA
Exit Power OFF
• Exit by the button on the title bar
• Exit from the System Menu
