5 Functionalities of Sysmac Studio
NA-series Programmable Terminal Soft-NA User’s Manual (V126)
5-1 Functionalities of Sysmac Studio
5
5-1-1 HMI Settings
The following functionalities have been deleted from the device settings.
Also, two items have been added as settings for the Soft-NA.
Device Settings
Functionality name Settings Description
Software Keypad/
USB Keyboard
USB keyboard
layout
Because the settings of the PC itself are used, make the settings
from Device under Windows Settings.
Screen Saver All Because the settings of the PC itself are used, make the settings
from Screen saver settings in Windows.
Screen Brightness All Because the settings of the PC itself are used, adjust the bright-
ness of the display to the required amount.
Sound All Not supported in Version 1.00.
No. Item Description
(a) Maximum Number of
Page Size
The page type specifies the size of the main page. The default value is
1280x800.
When the settings are changed, all pages in the device are expanded or
contracted according to the settings.
*1
*1. When the Maximum Number of Page Size is changed, depending on the project size, it may take 10 minutes
or more to execute the conversion process.
(b) Screen Mode Specifies the screen mode when the Soft-NA is started. The default value
is the Window Mode.
(a)
(b)
