TL-N/TL-Q/TL-G
DC 3-Wire Models
* The response frequency is an average value. Measurement conditions are as follows: standard sensing object, a distance of twice the standard sensing object, and
a set distance of half the sensing distance.
Item Model TL-Q2MC1 TL-Q5MC@ TL-G3D-3
Sensing
distance
2 mm ±15% 5 mm ±10% 7.5±0.5mm
Set distance 0 to 1.5 mm 0 to 4 mm 10 mm
Differential travel 10% max. of sensing distance
Detectable object Ferrous metal (The sensing distance decreases with non-ferrous metal. Refer to Engineering Data on page 6.)
Standard
sensing object
Iron, 8 × 8 × 1 mm Iron, 15 × 15 × 1 mm Iron, 10 × 5 × 0.5mm
Response time --- 2 ms max. 1 ms max.
Response
frequency *
500 Hz
Power supply
voltage (operating
voltage range)
12 to 24 VDC (10 to 30 VDC), ripple (p-p): 10% max. 12 to 24 VDC, ripple (p-p): 5% max.
Current
consumption
15 mA max. at 24 VDC (no-load) 10 mA max. at 24 VDC 2 mA max. at 24 VDC (no-load)
Con-
trol
output
Load
current
NPN open collector
100 mA max. at 30 VDC max.
NPN open collector
50 mA max. at 30 VDC max.
NPN transistor output
20 mA max.
Residual
voltage
1 V max. (under load current of 100 mA
with cable length of 2 m)
1 V max. (under load current of 50 mA
with cable length of 2 m)
---
Indicators Detection indicator (red) ---
Operation mode
(with sensing ob-
ject approaching)
NO
C1 Models: NO
C2 Models: NC
NO
Refer to the timing charts under I/O Circuit Diagrams on page 7 for details.
Protection
circuits
Reverse polarity protection, Surge suppressor Surge suppressor
Ambient
temperature range
Operating/Storage: −10 to 60°C (with
no icing or condensation)
Operating/Storage: −25 to 70°C (with no icing or condensation)
Ambient
humidity range
Operating/Storage: 35% to 95% (with no condensation)
Temperature
influence
±10% max. of sensing distance at 23°C
in the temperature range of −10 to 60°C
±20% max. of sensing distance at 23°C
in the temperature range of −25 to 70°C
±10% max. of sensing distance at 23°C
in the temperature range of −10 to 55°C
Voltage
influence
±2.5% max. of sensing distance at rated voltage in rated voltage ±10% range
Insulation
resistance
50 MΩ min. (at 500 VDC) between cur-
rent-carrying parts and case
5 MΩ min. (at 500 VDC) between current-carrying parts and case
Dielectric
strength
1,000 VAC for 1 min between current-
carrying parts and case
500 VAC, 50/60 Hz for 1 min between current-carrying parts and case
Vibration
resistance
Destruction: 10 to 55 Hz, 1.5-mm double amplitude for 2 hours each in X, Y, and Z directions
Shock resistance
Destruction: 1,000 m/s
2
10 times each
in X, Y, and Z directions
Destruction: 200 m/s
2
10 times each in X, Y, and Z directions
Degree of
protection
IEC 60529 IP67
,
in-house standards: oil-resistant
IEC IP67 IEC IP66
Connection
method
Pre-wired Models (Standard cable length: 2 m)
Pre-wired Models
(Standard cable length: 1m)
Weight
(packed state)
Approx. 30 g Approx. 60 g Approx. 30 g
Mate-
rials
Case
Heat-resistant ABS PPO
Sensing
surface
Accessories Instruction manual ---
