Omron TM5-700 Hardware Installation Manual

Regular Payload Series-Hardware Installation Manual TM5 Series Hardware Version: 3.2 28
Figure 14: Pictorial view of TM5-700 / TM5M-700 / TM5X-700 Movement Range Diagram
Figure 15: Top View of TM5-700 / TM5M-700 / TM5X-700 Movement Range
*All measures are in mm.
Operator
Position
Warning: Risk of crushing
within the operating area of
the arm.
Warning: Risk of collision
within the operating area of the
arm.

Omron TM5-700 Specifications

General

Brand	Omron
Model	TM5-700
Category	Robotics
Language	English
