Regular Payload Series-Hardware Installation Manual TM5 Series Hardware Version: 3.2 30
Figure 18: Top View of TM5-900 / TM5M-900 / TM5X-900 Movement Range
*All measures are in mm.
4.2.1.4 Robot Hazard Zone Diagram and Operator Position Diagram
Shown below is an illustration of the robot hazard zone and operator position diagrams. Do not operate
the robot while anyone is inside of the hazard zone to avoid safety risks.
Operator
Position
Warning: Risk of crushing
within
the operating area of the arm.
Warning: Risk of collision
within
the operating area of the arm.
