Omron TM5-700

Regular Payload Series-Hardware Installation Manual TM5 Series Hardware Version: 3.2 57
5.3.5 Analog Out
Figure 52: Analog Out
Range Resolution Accuracy Conversion Time
Analog In +10.00V~-10.00V 11bit ≤ 0.2% 1 ms
Analog Out +10.00V~-10.00V 11bit ± 0.07% 1 ms
Table 11: Analog In & Analog Out
5.3.6 System Remote Power ON/OFF
The function of Remote ON/OFF shares the same functionality of the Robot Stick Power Button.
Figure 53: System Remote Power ON/OFF
