Regular Payload Series-Hardware Installation Manual TM5 Series Hardware Version: 3.2 31
Figure 19: Robot Hazard Zone Diagram and Operator Position Diagram of TM5-700 / TM5M-700 / TM5X-700
*All measures are in mm.
TM5-700 / TM5M-700 / TM5X-700
Operator
Position
Warning: Risk of crushing within
the operating area of the arm.
Warning: Risk of collision within
the operating area of the arm.
