Omron V680-CA5D01-V2 - Page 132

129
RFID System
User’s Manual
SECTION 5
V680 Commands
SECTION 5
Communications
 COPY (CP)
The COPY command reads data from the memory of a Tag using one Antenna and writes it to the
memory of the Tag in the other Antenna's communications area. This command cannot be used with
the V680-CA5D01-V2.
 1:1 Protocol
The communications designation for the Antenna that reads data is always single trigger (ST). The communications
designation specified in the command is used for the Antenna that writes data.
For a communications designation that specifies repeating, data writing will be repeated for other Tags after data is writ-
ten to the first Tag.
Note: When using the multi-access trigger communications designation (MT), the ID controller returns
an end code of 03 after communicating with all Tags.
Communications
designation
Specifies the method of communications with the Tag.
Refer to Communications Designation Function for details on the communications designation.
p. 103
Data designation Always “H”.
Antenna designation Specifies the Antenna with which to communicate.
“1”: Reads from Antenna 1 and writes to Antenna 2.
“2”: Reads from Antenna 2 and writes to Antenna 1.
UID A unique identifier used to identify Tags.
Only in the case of the selective communications designation (SL), the UID of the Tag that is
being written to is added to the data.
Read area start address Specifies the start address of the area in the Tag from which data is to be read from in 4-digit
hexadecimal.
Setting range: 0000
H to FFFFH
No. of bytes to copy Specifies the number of bytes of data to copy in 4-digit hexadecimal.
Setting range: 0001
H to 0800H
Destination start address Specifies the start address of the area in the Tag to which data is to be written in 4-digit hexadec-
imal.
Setting range: 0000
H to FFFFH
UID A unique identifier used to identify Tags.
In the case of multi-access communications designations (MT/MR), the UID of the Tag that is
being written to is added to the data.
Data
desig-
nation
Read area start address
No. of bytes to copy
Destination start address
Terminator
Antenna
designation
Command
code
Communi-
cations
designation
××
××
CP
××
H1/2
××
244
11
××
2
××××
4
2
* CR
××
UID
××
0 or 16
...
Command
Response
Command
code
Terminator
End code
Antenna
desig-
nation
Resend flag
CP
00
22
2
* CR
0×
11
××
UID
××
0 or 16
...
