SECTION 5
V680 Commands
RFID System
User’s Manual
SECTION 5
Communications
 CONTROLLER CONTROL (CC)
The CONTROLLER CONTROL command is used to manipulate or read I/O.
 1:1 Protocol
OUT1/OUT2 controls 0: Read
1: Turn ON
2: Turn OFF
OUT3/OUT4 controls Output setting: Two Output Mode (BUSY, ERROR, OUT1, and OUT2)
Always “0”.
Output setting: Four Output Mode (OUT1, OUT2, OUT3, and OUT4)
0: Read
1: Turn ON
2: Turn OFF
TRG1/2 Input status The current input status
0: OFF
1: ON
OUT1/2 Output status The output status of OUT1 and OUT2 after execution.
0: OFF
1: ON
OUT3/4 Output status The output status of OUT3 and OUT4 after execution.
• Output setting: Two Output Mode (BUSY, ERROR, OUT1, and OUT2)
X: Fixed
• Output setting: Four Output Mode (OUT1, OUT2, OUT3, and OUT4)
0: OFF
1: ON
Command
Command
code
CC
2
2
* CR
Terminator
1
11
1
OUT1
control
OUT2
control
OUT3
control
OUT4
control
×
×
××
Response
CC
22
2
*
CR
0
1
0
1
0
1
0
1
0
1
0
1
0
1
0
1
Command
code
Terminator
End code
Resend flag
Fixed
value
×
TRG1
Input status
TRG2
Input status
OUT1
Output
status
OUT2
Output
status
OUT4
Output
status
OUT3
Output
status
×
