Omron V680-CA5D01-V2

229
RFID System
User’s Manual
SECTION 5
V600 Commands
SECTION 5
Communications
 1:N Protocol
Baud rate designation Specify the baud rate.
“3”: 9,600 bps
“4”: 19,200 bps
“5”: 38,400 bps
“6”: 115,200 bps
Default setting: 9,600 bps
Data length designation Specify the data length.
“7”: 7 bits
“8”: 8 bits
Default setting: 7 bits
Parity Specify the type of parity.
“0”: No parity
“1”: Odd parity
“2”: Even parity
Default setting: Even parity
Stop bit length Specify the number of stop bits.
“1”: 1 bit
“2”: 2 bits
Default setting: 2 bits
End code Indicates the execution result for the command.
“00” indicates a normal end.
Refer to List of End Codes for information on other end codes.
p. 235
Command
TR
21
2
*
CR
111
2
FCS
3
@
Command
code
Terminator
×
Baud
rate
desig-
nation Parity
Data length
designation
Stop bit
length
××× ××××
Controller No.
Response
TR
00
22
2
* CR
2
FCS
3
@
Command
code
Terminator
End code
Controller No.
×
×
×
×
