Omron V7 Quick Manual

EN-15
n044 Deceleration Time 4 10.0s
n045 Frequency reference bias
step amount (UP/DOWN
command 2)
0.00Hz
n046 Frequency reference bias ac-
cel/decel rate (UP/DOWN
command 2)
0
n047 Frequency reference bias op-
eration mode selection (UP/
DOWN command 2)
0
n048 Frequency reference bias val-
ue (UP/DOWN command 2)
0.0%
n049 Analog frequency reference
fluctuation limit level (UP/
DOWN command 2)
1.0%
n050 Multi-function Input Selection 1
(Terminal S1)
1
n051 Multi-function Input Selection 2
(Terminal S2)
2
n052 Multi-function Input Selection 3
(Terminal S3)
3
n053 Multi-function Input Selection 4
(Terminal S4)
5
n054 Multi-function Input Selection 5
(Terminal S5)
6
n055 Multi-function Input Selection 6
(Terminal S6)
7
n056 Multi-function Input Selection 7
(Terminal S7)
10
n057 Multi-function Output
Selection 1
0
n058 Multi-function Output
Selection 2
1
n059 Multi-function Output
Selection 3
2
n060 Analog Frequency Reference
Gain
100%
n061 Analog Frequency Reference
Bias
0%
n062 Filter Time Constant for
Analog Frequency Reference
0.10s
n063 SI-T/V7 W-DT Detection 0
Parameter
No.
Description Factory
Setting
n064 Frequency Reference
Loss Detection Selection
0
n065 Monitor Output Type 0
n066 Monitor Item Selection 0
n067 Monitor Gain 1.00
n068 Analog Frequency Reference
Gain (Voltage input from Opera-
tor)
100%
n069 Analog Frequency Reference
Bias (Voltage input from Opera-
tor)
0%
n070 Analog Frequency Reference
Filter Time Constant (Voltage
input from Operator)
0.10s
n071 Analog Frequency Reference
Gain (Current input from Opera-
tor)
100%
n072 Analog Frequency Reference
Bias (Current input from Opera-
tor)
0%
n073 Analog Frequency Reference
Filter Time Constant (Current
input from Operator)
0.10s
n074 Pulse Train Frequency
Reference Gain
100%
n075 Pulse Train Frequency
Reference Bias
0%
n076 Pulse Train Frequency
Filter Time Constant
0.10s
n077 Multi-function Analog Input
Function
0
n078 Multi-function Analog Input Sig-
nal Selection
0
n079 Frequency Reference Bias
(FBIAS) Value
10%
n080 Carrier Frequency Selection (Note3)
n081 Momentary Power Loss
Ridethrough Method
0
n082 Automatic Retry Attempts 0
n083 Jump Frequency 1 0.00Hz
Parameter
No.
Description Factory
Setting
I43-EN-01+V7+Quick_Guide.book Seite 15 Dienstag, 25. April 2006 8:56 08

Omron V7 Specifications

General

Series	V7
Cooling Method	Forced air cooling
Power Rating	0.4kW to 15kW
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Output Voltage	3-phase 200 to 240 VAC, 3-phase 380 to 480 VAC
