Omron V7 Quick Manual

EN-18
Multi-Function Inputs Multi-Function Outputs
Value Function Value Function
2 Reverse/Stop 0 Fault output
3 External fault (NO) 1 Running output
4 External fault (NC) 2 Frequency agree
5 Fault reset 6 Overtorque being Monitored (NO)
6 Multi-step reference 1 12 Run mode
7 Multi-step reference 2 13 Inverter ready
8 Multi-step reference 3 15 Undervoltage in progress
10 JOG command
Analogue Output Functions
12 External base block (NO) Value Function
13 External base block (NC) 0 Output frequency
17 Local/Remote selection 1 Output current
n172 Frequency reference bias
lower limit (UP/DOWN
command 2)
0.0%
n173 DC Injection Braking
Proportional Gain
83
(0.083)
n174 DC Injection Braking Integral
Time Constant
25
(100ms)
n175 Reducing Carrier Frequency
Selection at Low Speed
0
(Note5)
n176 Constant Copy Function
Selection
rdy
n177 Constant Read Selection
Prohibit
0
n178 Fault History -
n179 Software Version No. -
Parameter
No.
Description Factory
Setting
Note: Refer to user‘s manual
for complete list
1.Not initialized by constant
initialization.
2.Upper limit of setting range and
factory setting are doubled for
400V Class.
3.Depends on inverter capacity.
Refer to user’s manual.
4.When control mode selection
(n002) is changed, factory
setting corresponds to the
control mode. Refer to user’s
manual.
5.Enabled (1) for 5.5kW and
7.5kW inverters
Note: Refer to user’s manual for full set value listings
I43-EN-01+V7+Quick_Guide.book Seite 18 Dienstag, 25. April 2006 8:56 08

Omron V7 Specifications

General

Series	V7
Cooling Method	Forced air cooling
Power Rating	0.4kW to 15kW
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheating, Short Circuit
Output Voltage	3-phase 200 to 240 VAC, 3-phase 380 to 480 VAC
