Omron ZX-E Series User Manual

B-75ZX-E Series
ZX-E Series
ZX-series Communications Interface Unit
Cables with Connectors on Both Ends (for Extension)
30
4.2
3
64.3 4.2
31.5
36.813
(46)
(336)
15
13.2
11.7
6.5553
11.7
Connector
(33.1)
External terminal communications
indicator (communications operation)
External terminal communications
indicator (communications error)
Connector
Sensor communications indicator (communications operation)
Sensor communications indicator (communications error)
Power supply indicator
Vinyl-insulation round cable, 5.23 dia.
ZX-SF11
15 dia.
46
Vinyl-insulated round cable, 5.2 dia., 10 conductors
*ZX-XC1A: 1,000
ZX-XC4A: 4,000
ZX-XC8A: 8,000
44
15.5 dia.
12 pins (female)12 pins (male)
ZX-XC1A (1 m)
ZX-XC4A (4 m)
ZX-XC8A (8 m)
