ZX-E Series
Specifications
Sensor Heads
*1:Accuracy: The resolution is the deviation (±3σ) in the linear output when connected to the ZX-EDA Amplifier Unit. The above values indicate
the deviations observed 30 minutes after the power is turned ON.
(The resolution is measured with OMRON's standard reference object at 1/2 of the measurement range with the ZX-EDA set for the maxi-
mum average count of 4,096 per period.)
The resolution is given at the repeat accuracy for a stationary workpiece, and is not an indication of the distance accuracy. The resolution
may be adversely affected under strong electromagnetic fields.
*2: Linearity: The linearity is given as the error in an ideal straight line displacement output when measuring the standard reference object. The
linearity and measurement values vary with the object being measured.
*3: Temperature characteristic: The temperature characteristic is measured with OMRON's standard reference object at 1/2 of the measure-
ment range.
Model ZX-EDR5T ZX-ED01T ZX-ED02T/EM02T ZX-EM07MT
Measurement range
0 to 0.5 mm 0 to 1 mm 0 to 2 mm 0 to 7 mm
Sensing object
Magnetic metals (Measurement ranges and linearities are different for non-magnetic metals. Refer to
En-
gineering Data on B-67.)
Standard reference object
18× 18× 3 mm 30× 30× 3 mm 60× 60× 3 mm
Material: ferrous (S50C)
Accuracy *1
1 µm
Linearity *2
±0.5% F.S.
Linear output range
Same as measurement range.
Temperature characteristic *3
(including Amplifier Unit)
0.15% F.S./° C 0.07% F.S./° C
Ambient temper-
ature
Operating
0 to 50° C (with no icing
or condensation)
−10 to 60° C (with no icing or condensation)
Storage
0 to 50° C (with no icing
or condensation)
−20 to 70° C (with no icing or condensation)
Ambient humidity
Operating and storage: 35% to 85% (with no condensation)
Insulation resistance
50 MΩ min. (at 500 DC)
Dielectric strength
1,000 VAC, 50/60 Hz for 1 min between charged parts and case
Vibration resistance (destruction)
10 to 55 Hz with 1.5-mm double amplitude for 2 h each in X, Y, and Z directions
Shock resistance (destruction)
500 m/s
2
, 3 times each in X, Y, and Z directions
Degree of protection (Sensor Head)
IEC60529, IP65 IEC60529, IP67
Connection method
Connector relay (standard cable length: 2 m)
Weight (packed state)
Approx. 120 g Approx. 140 g
Approx. 160 g
Materials Sen-
sor
Head
Case
Brass Stainless steel
Brass
Sensing
surface
Heat-resistant ABS
Preamplifier
PES
Accessories
Amplifier Mounting Brackets (ZX-XBE1), Instruction Manual
