Omron ZX Series Manual

3
ZX SERIESZX SERIES
Specifications
■ Sensor Heads (Reflective)
Note: 1. Beam size: The beam size is defined by 1/e
2
(13.5%) of the strength of the beam at the beam center (measured value). Incorrect
detection may occur if there is light leakage outside the defined spot and the material around the target is more reflective than
the target.
2. Resolution: The resolution is the deviation (±3σ) in the linear output when connected to the ZX-LDA Amplifier Unit.
(The resolution is measured with the standard reference object (white ceramic), at the measurement point with the ZX-LDA set
for an average count of 4,096 per period.) The resolution is given at the repeat accuracy for a stationary workpiece, and is not
an indication of the distance accuracy. The resolution may be adversely affected under strong electromagnetic fields.
3. Linearity: The linearity is given as the error in an ideal straight line displacement output when measuring the standard reference
object. The linearity and measurement values vary with the object being measured.
4. Temperature characteristic: The temperature characteristic is measured at the measurement point with the Sensor and reference
object (OMRON’s standard reference object) secured with an aluminum jig.
5. Highly reflective objects can result in incorrect detection by causing out-of-range measurements.
Item Part number
ZX-LD40 ZX-LD100 ZX-LD300 ZX-LD30V ZX-LD40L ZX-LD100L ZX-LD300L Z3X-LD30VL
Optical system Diffuse reflective Regular
reflective
Diffuse reflective Regular
reflective
Light source (wave
length)
Visible-light semiconductor laser with a wavelength of 650 nm and an output of 1 mW max.; class 2
Measurement point 40 mm 100 mm 300 mm 30 mm 40 mm 100 mm 300 mm 30 mm
Measurement range ±10 mm ±40 mm ±200 mm ±2 mm ±10 mm ±40 mm ±200 mm ±2 mm
Beam shape Spot Line
Beam size
(See Note 1)
50-µm dia. 100-µm dia. 300-µm dia. 75-µm dia. 75 µm x 2
mm
150 µm x 2
mm
450 µm x 2
mm
100 µm x 1.8
mm
Resolution
(See Note 2)
2 µm 16 µm 300 µm 0.25 µm2 µm 16 µm 300 µm0.25 µm
Linearity (See Note 3) ±0.2% FS
(entire
range)
±0.2% FS
(80 to 120
mm)
±2% FS
(200 to 400
mm)
±0.2% FS
(entire
range)
±0.2% FS
(32 to 48
mm)
±0.2% FS
(80 to 120
mm)
±2% FS
(200 to 400
mm)
±0.2% FS
(entire range)
Temperature
characteristic
(See Note 4)
±0.03% FS/°C (Except for ZX-LD300 and ZX-LD300L, which are ±0.1% FS/°C.)
Ambient illumination Incandescent lamp: 3,000 l× max. (on light receiving side)
Ambient temperature Operating: 0 to 50°C, Storage: −15 to 60°C (with no icing or condensation)
Ambient humidity Operating and storage: 35% to 85% (with no condensation)
Insulation resistance 20 MΩ min. at 500 VDC
Dielectric strength 1,000 VAC, 50/60 Hz for 1 min
Vibration resistance
(destruction)
10 to 150 Hz, 0.7-mm double amplitude 80 min each in X, Y, and Z directions
Shock resistance
(destruction)
300 m/s
2
3 times each in six directions (up/down, left/right, forward/backward)
Degree of protection IEC60529, IP50 IEC60529,
IP40
IEC60529, IP50 IEC60529,
IP40
Connection method Connector relay (standard cable length: 500 mm)
Weight (packed state) Approx. 150 g Approx.
250 g
Approx. 150 g Approx. 250 g
Materials Case: PBT (polybutylene terephthalate)
Cover: Aluminum, Lens: Glass
Case and
cover:
Aluminum,
Lens: Glass
Case: PBT (polybutylene terephthalate)
Cover: Aluminum, Lens: Glass
Case and
cover:
Aluminum,
Lens: Glass
Accessories Instruction sheet, Laser warning label (English)
