■ Amplifier Units
Note: 1. The response speed of the linear output is calculated as the measurement period x (average count setting +1)
(with fixed sensitivity).
The response speed of the judgement outputs is calculated and the measurement period x (average count setting + 1)
(with fixed sensitivity).
2. The output can be switched between a current output and a voltage output using a switch on the bottom of the amplifier unit.
3. Setting is possible via the monitor focus function.
4. A calculating unit is required.
Item Part number
ZX-LDA11 ZX-LDA41
Measurement period 150 µs
Possible average count settings
(See Note 1)
1, 2, 4, 8, 16, 32, 64, 128, 256, 512, 1,024, 2,048, or 4,096
Temperature characteristic When connected to a Reflective Sensor Head: 0.01% FS/°C, When connected to a Through-beam
Sensor Head: 0.1% FS/°C
Linear output (See Note 2)
4 to 20 mA/FS, Max. load resistance: 300 Ω, ± 4 V [ ± 5 V, 1 to 5, 0 to 5 VDC (See Note 3)],
Output impedance: 100
Ω
Judgement outputs
(3 outputs: HIGH/PASS/LOW)
(See Note 1)
NPN open-collector outputs, 30 VDC, 50 mA max.
Residual voltage: 1.2 V max.
PNP open-collector outputs, 30 VDC, 50 mA max.
Residual voltage: 2 V max.
Laser OFF input, zero reset
input, timing input, reset input
ON: Short-circuited with 0-V terminal or 1.5 V or
less
OFF: Open (leakage current: 0.1 mA max.)
ON: Supply voltage short-circuited or supply
voltage within 1.5 V
OFF: Open (leakage current: 0.1 mA max.)
Functions Measurement value display, set value/light level/resolution display, scaling, display reverse, display OFF
mode, ECO mode, number of display digit changes, sample hold, peak hold, bottom hold, peak-to-peak
hold, self-peak hold, self-bottom hold, intensity mode, zero reset, initial reset,
ON-delay timer, OFF-delay timer, one-shot timer, deviation/sensitivity adjustment, keep/clamp switch,
direct threshold value setting, position teaching, 2-point teaching, automatic teaching,
hysteresis width setting, timing inputs, reset input, monitor focus, (A-B) calculations (See Note 4), (A+B)
calculations (See Note 4), mutual interference (See Note 4), laser deterioration detection, zero reset
memory, key lock
Indications Operation indicators: High (orange), pass (green), low (yellow), 7-segment main display (red),
7-segment subdisplay (yellow), laser ON (green), zero reset (green), enable (green)
Power supply voltage 12 to 24 VDC ±10%, Ripple (p-p): 10% max.
Current consumption 200 mA max. (with Sensor connected)
Ambient temperature Operating: 0 to 50°C, Storage: −15 to 60°C (with no icing or condensation)
Ambient humidity Operating and storage: 35% to 85% (with no condensation)
Insulation resistance 20 MΩ min. at 500 VDC
Dielectric strength 1,000 VAC, 50/60 Hz for 1 min
Vibration resistance (destruction) 10 to 150 Hz, 0.7 mm double amplitude 80 min each in X, Y, and Z directions
Shock resistance (destruction)
300 m/s
2
3 times each in six directions (up/down, left/right, forward/backward)
Connection method Prewired (standard cable length: 2 m)
Weight (packed state) Approx. 350 g
Materials Case: PBT (polybutylene terephthalate), Cover: Polycabonate
Accessories Instruction sheet
