ZX SERIESZX SERIES
Nomenclature
■ Sensor Heads and Amplifiers
Connecting Cable
Through-beam sensor to amplifier (1.5 m)
Amplifier Units
ZX-LDA11, ZX-LDA41
Sensor Heads (Reflective)
ZX-LD40, ZX-LD100, ZX-LD300, ZX-LD40L
ZX-LD100L, ZX-LD300L, ZX-LD30V, ZX-LD30VL
Calculating Unit
ZX-CAL
Receiver
(optical filter)
Output cable (with connector)
Input cable
(with connector)
Display area
Controls
Output cable
Connector
(Cover opens and closes.)
Display area
Connector
Display area
Sensor Heads (Through-beam)
ZX-LT001, ZX-LT005, ZX-LT010
Emitter
Laser ON indicator
(green)
Lit when light is emitted.
Light emitter
Receiver side
(Optical filter)
Emitter side
sensor head
connector
Receiver side sensor
head connector
Receiver
Emitter
Emitter-side Sensor
Head connector
Cable color: Gray
Receiver-side
Sensor Head
connector
Cable color: Black
Amplifier Unit
connector
