One Touch H700 - 9000 PB0710 I;O Board Pin Definition

Gladius H73X 3730
49
CON13 Audio line output EAR connector
PIN No. DESCRIPTION
1
EAROUT-L
2
GND
3
EAROUT-R
CON4&CON41 RS232 port COM1 and COM2 D-SUB connector
PIN No. Description
1
DCD
2
SIN (Rx)
3
SOUT (Tx)
4
DTR
5
GND
6
DSR
7
RTS
8
CTS
9
RI/DC output (RI is the default setting)
Pin9 signal can be selected as standard RI or DC power output depending on the JP2 and JP3
jumper settings. The default settings are for RI.
Attention: For devices using external power supplies and connected through Pin9 of COM1 or COM2, JP2
and JP3 should be open.
JP3 Description
1-2
PIN9 of COM1=DC +12V
3-4
PIN9 of COM1=RI (Default setting)
5-6
PIN9 of COM1=DC +5V
JP2 Description
1-2
PIN9 of COM2=DC +12V
3-4
PIN9 of COM1=RI(Default setting)
5-6
PIN9 of COM2=DC +5V
CON1 I/O Bus connector
PIN No. Description PIN No. Description
1
EAROUT_L
2
DIO_IN00
3
DIO_OUT01
4
DIO_OUT00
5
COM4_DTR
6
COM4_DSR
7
COM4_RTS
8
COM4_CTS
9
EAROUT_R
10
COM4_SOUT
11
COM2_CTS
12
COM2_RI
