One Touch H700 - Page 56

Gladius H73X 3730
50
13
COM2_DSR
14
COM2_RTS
15
COM2_SOUT
16
COM2_DTR
17
COM2_DCD
18
COM2_SIN
19
COM1_CTS
20
COM1_RI
21
COM1_DSR
22
COM1_RTS
23
COM1_SOUT
24
COM1_DTR
25
COM1_DCD
26
COM1_SIN
27
PC_CLK
28
PC_DATA
29
MOUSE_CLK
30
MOUSE_DATA
31
USB_1+
32
USB_1-
33
USB_0+
34
USB_0-
35
COM4_SIN
36
PRT_STB#
37
PRT_D0
38
PRT_D1
39
PRT_D2
40
PRT_D3
41
PRT_D4
42
PRT_D5
43
PRT_D6
44
PRT_D7
45
PRT_ACK#
46
PRT_PE
47
PRT_BUSY
48
PRT_SLCT
49
PRT_AED#
50
PRT_ERR#
51
PRT_INIT#
52
PRT_SLIN
53
LAN_L78
54
LAN_L78
55
LAN_L45
56
LAN_L45
57
LAN_RX-
58
LAN_RX+
59
LAN_TX-
60
LAN_TX+
CON12 Digital I/O signal and DC power connector
A 10 wire cable connects to 9000PB0710 secondary I/O board CN8, this supplies single and
power for the VFD customer display and Cash Drawer.
PIN No. Description
1
DIO_OUT00
2
DIO_OUT01
3
DIO_IN00
4
+5V
5
+5V
6
+12V
7
+12V
8
+12V
9
GND
10
GND
