One Touch H700 - 9000 PB0230 I;O Board Pin Definition

Gladius H73X 3730
53
PIN No. Description PIN No. Description
1
LAN_TX+
2
LAN_TX-
3
LAN_L45
4
LAN_RX+
5
LAN_RX-
6
LAN_L78
CN3 RJ45 LAN Port
PIN No. Description
1
LAN_TX+
2
LAN_TX-
3
LAN_RX+
4
LAN_L45
5
LAN_L45
6
LAN_RX-
7
LAN_L78
8
LAN_L78
CN10&CN11 USB port
PIN No. Description PIN No. Description
1
+5V
2
+5V
3
USB_0-
4
USB_1-
5
USB_0+
6
USB_1+
7
GND
8
GND
CN7 Cash drawer RJ11 Port
PIN No. DESCRIPTION
1
FG
2
L1-
3
SW+
4
DC +12V (L1+/L2+)
5
L2-
6
SW-
