One Touch H700 - Page 60

Gladius H73X 3730
54
CN4 VGA, COM4 and COM5 2x15 PIN header connector connects to the mainboard
J10 and J43
PIN
No
Description PIN
No
Description
1
NC
2
COM5_DSR
3
COM5_SIN
4
COM5_RTS
5
COM5_SOUT
6
COM5_CTS
7
COM5_DTR
8
NC
9
NC
10
NC
11
NC
12
COM4_DSR
13
COM4_SIN
14
COM4_RTS
15
COM4_SOUT
16
COM4_CTS
17
COM4_DTR
18
NC
19
NC
20
NC
21
RED
22
SM DATA
23
GREEN
24
SM CLK
25
BLUE
26
GND
27
H-SYNC
28
GND
29
V-SYNC
30
GND
CN5 VGA Port
PIN No. DESCRIPTION
1
RED
2
GREEN
3
BLUE
4
NC
5
GND
6
GND
7
GND
8
GND
9
NC
10
GND
11
NC
12
SM DATA
13
H-SYNC
14
V-SYNC
15
SM CLK
