Features and Specifications
ONePlus UPS User Instruction Manual 21
Specifications and Characteristics
Table 2. Physical/Electrical Specifications and Performance Characteristics
Specification and Characteristics ONePlus250 ONePlus400 ONePlus600 ONePlus1000
Part Number ONE254AG-SE ONE404AG-SE ONE604AG-SE ONE1004AG-SE
Maximum Load VA/W 250/167 400/268 600/402 1000/670
Rated Power Factor UPS .67
Crest Factor <3
Nominal Input Voltage 120 VAC
Low Limit for On-line Operation 89 VAC
High Limit for On-line Operation 152 VAC
Frequency Limits (on-line) 60Hz +/ -5%
Input Connection 6’ attached line cord with 5-15P plug
Input Over Current Protection resettable circuit breaker
Buck and Boost
maintains output voltage between 101 and 132 VAC
while input voltage varies between 89 and 152 VAC
Nominal Output Voltage (on battery) 115 VAC
On Battery Waveshape sine-wave
On Battery Frequency 60Hz +/- 1%
Transfer Time 6mS, max
Output Connection
(4) 5-15R (4) 5-15R (6) 5-15R (8) 5-20R (T*)
Battery Type maintenance free, spill proof, sealed lead-acid
Typical Battery Life 2 - 4 years, depends on number of discharges and ambient temperature
Typical Battery Recharge Time
(90% Recovery)
3-6 hours after full discharge to cut off
Communications isolated basic signaling
Interface Connector USB and RS232 communications ports
Input Signal - static
inverter shut down [pin 2 (+) to pin 5 (common)]
(+3 to +27 VDC shuts down inverter)
Output Signals - stimulated relay
on battery (pin 9 N.O., (N.C.), pin 5 (common)
Low battery (pin 1 N.O.)
Maximum Collector Voltage 25 VDC
Maximum Collector Current 25 mADC
Operating Temperature** 0 to +40° C (32 to 104° F)
Storage Temperature** -15 to 45° C (+5 to 113° F)
Relative Humidity 0 to 95%, non-condensing
Table continued on next page.
