Oneida Air Systems Supercell - Wall Bracket Dimensions

8 Oneida Air Systems
Nominal dimensions shown. Dimensions subject to slight variations in manufacturing.
Wall Bracket Dimensions
2"
51 mm
2"
51 mm
8"
203 mm
16"
406 mm
1/2"
13 mm
6"
152 mm
20"
508 mm
Floor
30 Gallon: 45-13/16" ; 1163 mm
30 Gallon with Dolly: 49-13/16" ; 1265 mm
35 Gallon: 38-1/2" ; 978 mm
35 Gallon with Dolly: 42-1/2" ; 1080 mm
55 Gallon: 49-7/8"; 1267 mm
55 Gallon with Dolly: 53-7/8"; 1368 mm
15-1/4"
388 mm
