Oneida Air Systems Supercell - System Dimensions with 35 Gallon Drum

10 Oneida Air Systems
Nominal dimensions shown. Dimensions subject to slight variations in manufacturing.
Allow for an additional 24" of clearance above the Motor Assembly to allow for its removal during lter replacement and other
maintenance. If you purchased the Universal Drum Dolly, add an additional 4" to the height of the unit.
System Dimensions with 35 Gallon Drum
71-7/8"
1,826 mm
24-1/4"
616 mm
22-1/4"
565 mm
47-5/8"
1210 mm
21-9/16"
548 mm
Top View
20"
508mm
23-1/2"
508mm
23-3/4"
508mm
