Oneida Air Systems Supercell - System Dimensions with 55 Gallon Drum

11oneida-air.com
System Dimensions with 55 Gallon Drum
24-1/4"
616 mm
59"
1,499 mm
35"
889 mm
21-9/16"
548 mm
Top View
Nominal dimensions shown. Dimensions subject to slight variations in manufacturing.
Allow for an additional 24" of clearance above the Motor Assembly to allow for its removal during lter replacement and other
maintenance. If you purchased the Universal Drum Dolly, add an additional 4" to the height of the unit.
20"
508 mm
23-1/2"
597 mm
23-3/4"
603 mm
83-1/4"
2,115 mm
