Oneida Air Systems Supercell - System Dimensions with 30 Gallon Drum

9oneida-air.com
Nominal dimensions shown. Dimensions subject to slight variations in manufacturing.
Allow for an additional 24" of clearance above the Motor Assembly to allow for its removal during lter replacement and other
maintenance. If you purchased the Universal Drum Dolly, add an additional 4" to the height of the unit.
System Dimensions with 30 Gallon Drum
24-1/4"
616 mm
54-15/16"
1,395 mm
29-9/16"
751 mm
21-9/16"
548 mm
Top View
20"
508mm
23"
584 mm
79-3/16"
2,011 mm
