6.4 Examples
6.4.1 Connecting one MVX with one PC in a point to point
connection through the MVX right port
In this example the PC and the MVX may be let in the dynamic IP address mode.
MVX: dynamic IP mode
Default address: serial number
used as “Hostname”
(IP = 169.254.x.y)
MVX : B
Ethernet port
Standard
Straight cable
PC, dynamic IP
mode
