7.3.5 Status of indicators
The logical status of each indicator can take 4 different values:
Value of logical status
Description of indicator status
0
Normal (OK)
1
Alarm
2
Danger
3
Defect (transducer or other defect making measurement
impossible)
At address 2000, one can read hexadecimal 5555 value permanently, which allows
checking the proper operating of the transfer connection.
Logical statuses of indicators are available in an address range from 2000 to 2256
and sorted according to the table below:
MODBUS memory address
Content
2000
Hexadecimal 5555, set value
2001
Logical status of indicator #1
2002
Logical status of indicator #2
…
..
…
..
2256
Logical status of indicator #256
