Onkyo A-9030 Service Manual

A-9050
Exploded Views - 3
A
1
2
3
4
5
B C D
U0011
U0030
A102
A101
A001
U0015
U0013
T901
U0014
U0010
U0016
A012
A011
A010
838430088GR
Other Screws:
3TTB+8B(3BC)
A013
A015 x 5PCS.
Q526
Q524
Q528
Q525
D900
Q523
Q527
Q529
A020 x 4PCS.
A020
x 4PCS.
x 2PCS.
A111
x 2PCS.
A005
x 7PCS.
A003
x 4PCS.
A002
x 4PCS.
Q530
Q527A,Q528A,Q529A,Q530A

Onkyo A-9030 Specifications

General

Damping factor	60
Amplifier class	A/B
Frequency range	10 - 100000 Hz
Output impedance	8 Ω
Audio output channels	2.0 channels
Peak power per channel	- W
Signal-to-Noise Ratio (SNR)	105 dB
Total Harmonic Distortion (THD)	0.08 %
RMS power output per channel (1 Ohm)	65 W
Audio (L/R) in	5
Audio (L/R) out	1
Speakers connectivity type	Clamp terminals
Purpose	Home
Material	Aluminium, Metal
Product color	Silver
Volume control	Rotary
Bass adjustment	Yes
Connectivity technology	Wired
Built-in display	No
AC input voltage	220-230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	135 W
Package weight	9400 g

Weight and Dimensions

Depth	330.3 mm
Width	435 mm
Height	139 mm
Weight	7400 g
