Onkyo A-933 Service Manual

43/46 PAGE
PCB3
R760 C-CARBON R RN72K1J-331JE 1 435033314R1
PCB3
R761 C-CARBON R RN72K1J-331JE 1 435033314R1
PCB3
R762 C-CARBON R RN72K1J-181JE 1 435031814R1
PCB3
R763 C-CARBON R RN72K1J-331JE 1 435033314R1
PCB3
R764 C-CARBON R RN72K1J-331JE 1 435033314R1
PCB3
R765 C-CARBON R RN72K1J-331JE 1 435033314R1
PCB3
R766 C-CARBON R RN72K1J-391JE 1 435033914R1
PCB3
R767 C-CARBON R RN72K1J-181JE 1 435031814R1
PCB3
R768 C-CARBON R RN72K1J-332JE 1 435033324R1
PCB3
R769 C-CARBON R RN72K1J-103JE 1 435031034R1
PCB3
R770 C-CARBON R RN72K1J-103JE 1 435031034R1
PCB3
R771 C-CARBON R RN72K1J-000JE 1 435030004R1
PCB3
R772 C-CARBON R RN72K1J-000JE 1 435030004R1
PCB3
R901 THERMISTOR S5R114 1 4000147
!
PCB3
R902 THERMISTOR S5R114 1 4000147
!
PCB3
R903 THERMISTOR S5R114 1 4000147
!
PCB3
R904 THERMISTOR S5R114 1 4000147
!
PCB3
R905 METAL R RNU1/2WCJ-0.47 1 453534794
PCB3
R906 METAL R RNU1/2WCJ-0.47 1 453534794
PCB3
R907 METAL R RNU1/2WCJ-0.22 1 453532294
PCB3
R908 C-CARBON R RN72K1J-103JE 1 435031034R1
PCB3
R909 C-CARBON R RN72K1J-273JE 1 435032734R1
PCB3
R910 C-CARBON R RN72K1J-103JE 1 435031034R1
PCB3
R921 C-CARBON R RN72K1J-333JE 1 435033334R1
PCB3
R922 C-CARBON R RN72K1J-183JE 1 435031834R1
PCB3
R923 C-CARBON R RN72K1J-273JE 1 435032734R1
PCB3
RL901 RELAY NRL-1P5A-DC9-185 1 25065680
!
PCB3
RL902 RELAY NRL-1P5A-DC9-185 1 25065680
!
PCB3
S701 ROT SW NRSF-112-20SRM 1 25030424
PCB3
S702 PUSH SW NPS-111-S604 1 25035652
PCB3
S703 PUSH SW NPS-111-S604 1 25035652
PCB3
S704 PUSH SW NPS-111-S604 1 25035652

Onkyo A-933 Specifications

General

Frequency range	10 - 60000 Hz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Product color	Black
Dimensions (WxDxH)	275 x 103 x 328 mm
Power requirements	AC 220-240 V, 50 Hz
Power consumption (standby)	0.9 W
Power consumption (typical)	100 W

Weight and Dimensions

Weight	7500 g
