Onkyo A-933 Service Manual

44/46 PAGE
PCB3
S705 PUSH SW NPS-111-S604 1 25035652
PCB3
S706 PUSH SW NPS-111-S604 1 25035652
PCB3
S901 P SW NPS-111-L512P 1 25035550
!
PCB3
P701A SOCKET NSCT-15P2249 1 25052352
PCB3
P702 SOCKET AS NSAS-6P1199 1 20064390610UL
PCB3
P705 SOCKET AS NSAS-4P1537 1 2009990970UL
PCB3
P901A PLUG NPLG-2P631 1 25055675
!
PCB3
P902 CRIMP AS CRIMP AS 1 2069943141UL
!
PCB3
P903 CRIMP AS CRIMP AS 1 2069943149UL
!
PCB3
P904 SOCKET AS NSAS-4P1522 1 2009990964UL
!
PCB3
P904A PLUG NPLG-2P632 1 25055676
!
PCB3
P905 CRIMP AS CRIMP AS 1 2069943129UL
!
PCB3
P906A PLUG NPLG-2P631 1 25055675
!
PCB3
P907A PLUG NPLG-2P631 1 25055675
!
PCB3
P911 SOCKET NSCT-2P1424 1 25051637
!
PCB3
E901 RETAINER KANAGU 1 27141059
PCB3
E911 TRM(SCREW) NEGITANSI M3 1 25065425
PCB3
E912 TRM(SCREW) NEGITANSI M3 1 25065425
PCB3
F901A FUSE HOL NSCT-1P2031 1 25052133
!

Onkyo A-933 Specifications

General

Frequency range	10 - 60000 Hz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.08 %
Product color	Black
Dimensions (WxDxH)	275 x 103 x 328 mm
Power requirements	AC 220-240 V, 50 Hz
Power consumption (standby)	0.9 W
Power consumption (typical)	100 W

Weight and Dimensions

Weight	7500 g
