Onkyo HT-R410 Service Manual

HT-R410
BLOCK DIAGRAM
AC OUTLET
P351
Q306
KRA102S
C352
104Z
BASSBOOST
OPAMP
OUTPUT GAIN
0-18dB
OPAMP
OUTPUT GAIN
0-18dB
OPAMP
OUTPUT GAIN
0-18dB
OPAMP
OUTPUT GAIN
0-18dB
OPAMP
OUTPUT GAIN
0-18dB
OPAMP
OUTPUT GAIN
0-18dB
0
/6dB
N
0/6dB
N
0/6dB
N
0/6dB
0
/6dB
AIN
/
6dB
Q305
OPAMP
15dB
47/16
47/16
47/16
47/16
47/16
47/16
SEC1H RELAY
POWER
RELAY
MASTER
VOLUME
0,-103dB
SEC2
BASS/TREBLE
BASS/TREBLE
AC IN
T901
PRI
SEC1
T902
RI
SEC3
+B1L
+B1H
HEADPHONE
+5V
DSP/TU
-12V
+12V
AF/TU
+12V
AF
-12V
11
8
11
VOLTAGE
SENSOR
VOLH
PROTE
CTION
PRO
VOLTAGE &
CURRENT
SENSOR
VIDEO
+12V
-27V
-VP
FL TUBE
FLAC
FLAC
SEC1H
CONTROL
RELAY
+B2
SEC1H
+B1
+5.6V
STANDBY
POWER
RI
INTERFACE
+27dB
+27dB
+27dB
+27dB
+27dB
FUSE
L
R
C
SL
SR
SPBL
SPBR
2.2K
2.2K
2.2K
2.2K
2.2K
R385
100
R388
100
270
69
68
55
66
65
57
43
42
38
40
39
37
30
31
35
33
34
36
SWPO
AMUT
SPF
SPCS
SPB
HPDET
SELMUT
SELDA
SELCL
LAY
Power Amplifier
A
1
2
3
4
5
BCD

Onkyo HT-R410 Specifications

Amplifier Section

Power Output Front L/R Speakers	100 Watts per channel min. RMS at 8 ohms 2 channel driven, 20-20, 000 Hz, 0.08% THD
Power Output Center Speaker	100 Watts min. RMS at 8 ohms, 20-20, 000 Hz, 0.08% THD
Power Output Surround L/R Speakers	100 Watts per channel min. RMS at 8 ohms 2 channel driven, 20-20, 000 Hz, 0.08% THD
Dynamic Power Output at 3 ohms	230 watts × 2
Dynamic Power Output at 4 ohms	170 watts × 2
Dynamic Power Output at 8 ohms	115 watts × 2

Input and Output Impedance

Digital Input Optical	0.5 Vp-p, 75 ohms
Digital Input Coaxial	0.5 Vp-p, 75 ohms
Line Input (CD, VIDEO 1, 2, 3, TAPE)	200 mV, 47 kohms
Multichannel Input (DVD FRONT L/C/R, SURR L/R)	200 mV, 47 kohms
Multichannel Input (SUBWOOFER)	36 mV, 47 kohms
Output Level Rec out (TAPE, VIDEO 1)	200 mV, 470 ohms
Output Level Pre out (SUBWOOFER)	1 V, 470 ohms

Tuner Section

FM Tuning Range	87.5-108.0 MHz (100 kHz steps)
FM Usable Sensitivity Mono	11.2 dBf, 1.0 µV (75 ohms, IHF)
FM Usable Sensitivity Stereo	17.2 dBf, 2.0 µV (75 ohms, IHF)
FM 50 dB Quieting Sensitivity Mono	17.2 dBf, 2.0 µV (75 ohms)
FM 50 dB Quieting Sensitivity Stereo	37.2 dBf, 20.0 µV (75 ohms)
FM Capture Ratio	2.0 dB
FM Image Rejection Ratio	40 dB
FM IF Rejection Ratio	90 dB
FM Signal-to-Noise Ratio Mono	76 dB, IHF
FM Signal-to-Noise Ratio Stereo	70 dB, IHF
FM Alternate Channel Attenuation	55 dB, IHF, ±400 kHz
FM Selectivity	50 dB (DIN)
FM AM Suppression Ratio	50 dB
FM Total Harmonic Distortion Mono	0.2%
FM Total Harmonic Distortion Stereo	0.3%
FM Frequency Response	30 Hz-15 kHz, ±1.0 dB
FM Stereo Separation at 1 kHz	45 dB
FM Stereo Separation at 100 Hz-10 kHz	30 dB
AM Tuning Range	530-1, 710 kHz (10 kHz steps)
AM Usable Sensitivity	30 µV
AM Image Rejection Ratio	40 dB
AM IF Rejection Ratio	40 dB
AM Signal-to-Noise Ratio	40 dB
AM Total Harmonic Distortion	0.7%

General Specifications

Power Supply	AC 120 V, 60 Hz
Power Consumption	4.7 A
Dimensions (W × H × D)	17-1/8” × 5-7/8” × 14-3/8”
Dimensions in mm (W × H × D)	435 × 150 × 365 mm
Weight	19.0 lbs., 8.6 kg
