Onkyo HT-R410 Service Manual

HT-R410
SCHEMATIC DIAGRAM 1 Display/Video sections
P7502A
C7523 102J
C7522
101J
F2 F2 NP NP P35 P34 P33 P32 P31 P30 P29 P28 P27 P26 P25 P24 P23 P22 P21 P20 P19 P18 P17 P16 P15 P14 P13 P12 P11 P10 P9 P8 P7 P6 P5 P4 P3 P2 P1 16G 15G 14G 13G 12G 11G 10G 9G 8G 7G 6G 5G 4G 3G 2G 1G NP NP F1 F1
Q7501 HNA-16MM39T
1 2 3 4 5 6 7 8 9
10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52 53 54
55 56 57 58 59
JL7501B JL7501A
S7615
SP B
S7616
SP A
S7614
STANDBY
S7647
AUDIO
ADJUST
S7645
PRE SET<
S7644
DSP
S7643
SURRO UND
S7642
STEREO
S7641
DIRECT
S7646
PRE SET>
S7635
MEM ORY
S7634
TAPE
S7633
TUNER
S7632
CD
S7631
SP
ADJUST
S7636
TUNI NG<
S7637
TUNI NG<
S7627
FM MODE
S7625
VIDEO2
S7624
VIDEO1
S7623
DVD
S7622 AUDIO
SEL
S7621
DIS PLAY
S7626
VIDEO3
S7613
DIMMER
S7612
SW MODE
S7611
DIGITAL
INPUT
P7503
A
S7501
Q7504
RN2403
*KRA103S
U7501
SPS4441E1
L7505
220K
NCH1477
Q7502
UPD780232GC-030-8BT
21:ANI1
21
22:ANI0
22
41:P45/FIP37
41
42:P44/FIP36
42
43:P43/FIP35
43
61:FIP19
61
ANI220 ANI319
AVDD24
AVSS18
FIP0
80
FIP1 79
FIP10 70
FIP11 69
FIP12 68
FIP13 67
FIP14 66
FIP15 65
FIP16 64
FIP17 63
FIP18 62
FIP2 78
FIP20 58 FIP21 57 FIP22 56 FIP23 55
FIP3 77
FIP4 76
FIP5 75
FIP6 74
FIP7 73
FIP8 72
FIP9 71
IC5 P01/INTP116 P02/TI17 P20/SCK314 P21/SO313 P2212 P2311 P24/BUSY10 P25SO19 P26/SI18 P27/SCK17 P30/FIP24 54
P31/FIP25 53 P32/FIP26 52 P33/FIP27 51 P34/FIP28 50 P35/FIP29 49 P36/FIP30 48 P37/FIP31 47 P40/FIP32 46 P41/FIP33 45 P42/FIP34 44
P46/FIP3840
P47/FIP3939
P50/FIP4038
P51/FIP4137
P52/FIP4236
P53/FIP4335
P54/FIP4434
P55/FIP4533
P56/FIP4632
P57/FIP4731
P60/FIP4830
P61/FIP4929
P62/FIP5028
P63/FIP5127
P64/FIP5226
POO/INTP015
VDD025
VDD1
1
VDD2 59
VLOAD
60
VSS023
VSS12 X13 X2
4
RESET
6
R7519
100K
R7614
820
R7613
560
R7524 1K
R7646 2.2K
R7615
1.2K
R7531
220
R7641 330R7645 1.2K R7644 820 R7643 560 R7642 470
R7631
330R7632 470R7633 560R7634 820R7635 1.2KR7636 2.2K
R7626
2.2K R7621 330R7625 1.2K R7624 820 R7623 560 R7622 470
R7612
470 R7611 330
Q7506
RN1402
*KRC102S
X7501
CST5.00MGW
Q7503
2SC2712
*KTC3875
D7505
STANDBY
D7502
UDZ5.1B
D7507
1SS352
D7503
1SS352
C7514 100/6.3
C7502
C7513 104Z
C7515
104Z
C7516
104Z
C7517
102J
C7508 102J
C7509 102J
C7507
104Z
C7510 102J
C7511 102J
R7518
100K
R7517 1K
R7503
10K
R7520
2.7K
R7521 2.7K
R7504
47K
R7507
4.7K
R7506
4.7K
R7532
10K
R7527
10K
R7526 10K
R7530 1K
R7529
560
R7528
560
R7508
4.7K
R7509
4.7K
R7510
1K
R7511
1K
R7512
10K
R7513
10K
R7514 10K R7515
10K
R7516
10K
R7522 2.7K
R7523 2.7K
R7505
220K
SYSOUT
IRF
VAJ VBJ
STBYLED
SYSIN
K0 K1 K2 K3
SBMLDY
SBMDI SBMDO
SBMCLK SBMRST
K0 K1 K2
K3
GND
KEY0
SYSIN HPDET
SBMLDY
SBMDI SBMDO
SBMCLK SBMRST
-VP
NASW-7404
NADIS-7403
TO NADG-7401(SCH-2)
U2
U3
A
1
2
3
4
5
BCD

Onkyo HT-R410 Specifications

Amplifier Section

Power Output Front L/R Speakers	100 Watts per channel min. RMS at 8 ohms 2 channel driven, 20-20, 000 Hz, 0.08% THD
Power Output Center Speaker	100 Watts min. RMS at 8 ohms, 20-20, 000 Hz, 0.08% THD
Power Output Surround L/R Speakers	100 Watts per channel min. RMS at 8 ohms 2 channel driven, 20-20, 000 Hz, 0.08% THD
Dynamic Power Output at 3 ohms	230 watts × 2
Dynamic Power Output at 4 ohms	170 watts × 2
Dynamic Power Output at 8 ohms	115 watts × 2

Input and Output Impedance

Digital Input Optical	0.5 Vp-p, 75 ohms
Digital Input Coaxial	0.5 Vp-p, 75 ohms
Line Input (CD, VIDEO 1, 2, 3, TAPE)	200 mV, 47 kohms
Multichannel Input (DVD FRONT L/C/R, SURR L/R)	200 mV, 47 kohms
Multichannel Input (SUBWOOFER)	36 mV, 47 kohms
Output Level Rec out (TAPE, VIDEO 1)	200 mV, 470 ohms
Output Level Pre out (SUBWOOFER)	1 V, 470 ohms

Tuner Section

FM Tuning Range	87.5-108.0 MHz (100 kHz steps)
FM Usable Sensitivity Mono	11.2 dBf, 1.0 µV (75 ohms, IHF)
FM Usable Sensitivity Stereo	17.2 dBf, 2.0 µV (75 ohms, IHF)
FM 50 dB Quieting Sensitivity Mono	17.2 dBf, 2.0 µV (75 ohms)
FM 50 dB Quieting Sensitivity Stereo	37.2 dBf, 20.0 µV (75 ohms)
FM Capture Ratio	2.0 dB
FM Image Rejection Ratio	40 dB
FM IF Rejection Ratio	90 dB
FM Signal-to-Noise Ratio Mono	76 dB, IHF
FM Signal-to-Noise Ratio Stereo	70 dB, IHF
FM Alternate Channel Attenuation	55 dB, IHF, ±400 kHz
FM Selectivity	50 dB (DIN)
FM AM Suppression Ratio	50 dB
FM Total Harmonic Distortion Mono	0.2%
FM Total Harmonic Distortion Stereo	0.3%
FM Frequency Response	30 Hz-15 kHz, ±1.0 dB
FM Stereo Separation at 1 kHz	45 dB
FM Stereo Separation at 100 Hz-10 kHz	30 dB
AM Tuning Range	530-1, 710 kHz (10 kHz steps)
AM Usable Sensitivity	30 µV
AM Image Rejection Ratio	40 dB
AM IF Rejection Ratio	40 dB
AM Signal-to-Noise Ratio	40 dB
AM Total Harmonic Distortion	0.7%

General Specifications

Power Supply	AC 120 V, 60 Hz
Power Consumption	4.7 A
Dimensions (W × H × D)	17-1/8” × 5-7/8” × 14-3/8”
Dimensions in mm (W × H × D)	435 × 150 × 365 mm
Weight	19.0 lbs., 8.6 kg
