Onkyo HT-R410 Service Manual

Q7502
SUB-MICROPROCESSOR
UPD780232GC
K1
21
K0
22
P45/FIP37
41
P44/FIP36
42
P43/FIP35
43
FIP19
61
ANI220 ANI319
AVDD
24
AVSS18
FIP0
80
FIP1
79
FIP10
70
FIP11
69
FIP12
68
FIP13
67
FIP14
66
FIP15
65
FIP16
64
FIP17
63
FIP18
62
FIP2
78
FIP20 58 FIP21 57 FIP22
56
FIP23 55
FIP3
77
FIP4
76
FIP5
75
FIP6
74
FIP7
73
FIP8
72
FIP9
71
IC5 P01/INTP116 P02/TI17 P20/SCK314 P21/SO313 P2212 P2311 P24/BUSY10 P25SO19 P26/SI18 P27/SCK17
P30/FIP24
54
P31/FIP25
53
P32/FIP26
52
P33/FIP27
51
P34/FIP28
50
P35/FIP29
49
P36/FIP30
48
P37/FIP31
47
P40/FIP32
46
P41/FIP33
45
P42/FIP34
44
P46/FIP38
40
P47/FIP39
39
P50/FIP40
38
P51/FIP41
37
P52/FIP42
36
P53/FIP43
35
P54/FIP44
34
P55/FIP45
33
P56/FIP46
32
P57/FIP47
31
P60/FIP48
30
P61/FIP49
29
P62/FIP50
28
SYSOUT
27
SYSIN
26
POO/INTP015
VDD0
25
VDD11
VDD2 59
VLOAD 60
VSS0
23
VSS12 X13 X2
4
RESET
6
Q7501
FL TUBE
HNA-16MM39T
Q7504
BUFFER
S7627
FM MODE
S7625
VIDEO2
S7624
VIDEO1
S7623
DVD
S7622 AUDIO
SEL
S7621
DISPLAY
S7626
VIDEO3
2.2K 3301.2K 820 560 470
S7635
MEMORY
S7634
TAPE
S7633
TUNER
S7632
CD
S7631
SP
ADJUST
S7636
TUNING<
S7637
TUNING<
3304705608201.2K2.2K
S7647
AUDIO
ADJUST
S7645
PRESET<
S7644
DSP
S7643
SURRO UND
S7642
STEREO
S7641
DIRECT
S7646
PRESET>
2.2K 3301.2K 820 560 470
S7615
SP-B
S7614
STANDBY
S7613
DIMMER
S7612
SW MODE
S7611
DIGITAL INPUT
S7616
SP-A
3301.2K 820 560 470
P282
RI
K2
K3
U7501
SPS4441E1
IRF
Q7506
D7505
STANDBY IND.
K2
S7501
MAIN
VOLUME
Q7008
MAIN
MICROPROCESSOR
X7501
5MHZ
OSC
HT-R410
SUB-MICROPROCESSOR
CONNECTION DIAGRAM
HT-R410
A
1
2
3
4
BCDE

Onkyo HT-R410 Specifications

Amplifier Section

Power Output Front L/R Speakers	100 Watts per channel min. RMS at 8 ohms 2 channel driven, 20-20, 000 Hz, 0.08% THD
Power Output Center Speaker	100 Watts min. RMS at 8 ohms, 20-20, 000 Hz, 0.08% THD
Power Output Surround L/R Speakers	100 Watts per channel min. RMS at 8 ohms 2 channel driven, 20-20, 000 Hz, 0.08% THD
Dynamic Power Output at 3 ohms	230 watts × 2
Dynamic Power Output at 4 ohms	170 watts × 2
Dynamic Power Output at 8 ohms	115 watts × 2

Input and Output Impedance

Digital Input Optical	0.5 Vp-p, 75 ohms
Digital Input Coaxial	0.5 Vp-p, 75 ohms
Line Input (CD, VIDEO 1, 2, 3, TAPE)	200 mV, 47 kohms
Multichannel Input (DVD FRONT L/C/R, SURR L/R)	200 mV, 47 kohms
Multichannel Input (SUBWOOFER)	36 mV, 47 kohms
Output Level Rec out (TAPE, VIDEO 1)	200 mV, 470 ohms
Output Level Pre out (SUBWOOFER)	1 V, 470 ohms

Tuner Section

FM Tuning Range	87.5-108.0 MHz (100 kHz steps)
FM Usable Sensitivity Mono	11.2 dBf, 1.0 µV (75 ohms, IHF)
FM Usable Sensitivity Stereo	17.2 dBf, 2.0 µV (75 ohms, IHF)
FM 50 dB Quieting Sensitivity Mono	17.2 dBf, 2.0 µV (75 ohms)
FM 50 dB Quieting Sensitivity Stereo	37.2 dBf, 20.0 µV (75 ohms)
FM Capture Ratio	2.0 dB
FM Image Rejection Ratio	40 dB
FM IF Rejection Ratio	90 dB
FM Signal-to-Noise Ratio Mono	76 dB, IHF
FM Signal-to-Noise Ratio Stereo	70 dB, IHF
FM Alternate Channel Attenuation	55 dB, IHF, ±400 kHz
FM Selectivity	50 dB (DIN)
FM AM Suppression Ratio	50 dB
FM Total Harmonic Distortion Mono	0.2%
FM Total Harmonic Distortion Stereo	0.3%
FM Frequency Response	30 Hz-15 kHz, ±1.0 dB
FM Stereo Separation at 1 kHz	45 dB
FM Stereo Separation at 100 Hz-10 kHz	30 dB
AM Tuning Range	530-1, 710 kHz (10 kHz steps)
AM Usable Sensitivity	30 µV
AM Image Rejection Ratio	40 dB
AM IF Rejection Ratio	40 dB
AM Signal-to-Noise Ratio	40 dB
AM Total Harmonic Distortion	0.7%

General Specifications

Power Supply	AC 120 V, 60 Hz
Power Consumption	4.7 A
Dimensions (W × H × D)	17-1/8” × 5-7/8” × 14-3/8”
Dimensions in mm (W × H × D)	435 × 150 × 365 mm
Weight	19.0 lbs., 8.6 kg
